Summary
Overview
KENWOOD eXcelon products are specially developed to provide the ideal listening experience.
Maximum precision is achieved with top-end components for true musical indulgence. Receivers feature innovative technologies such as advanced smartphone connectivity and driver safety options.
We stand firmly behind the eXcelon products with a 2 Year Warranty.
Features
Woofers: The woofer cones are made of injection-molded polypropylene. This process of cone molding assures a uniform cone thickness for superior linearity and clarity. It is also light weight and rigid for decreased distortion and improved bass response.
Mounting: Without an adapter, the KFC-X174 speakers fit standard 6-3/4" applications. Given their required cutout, they will also fit 6-1/2" applications without an adapter, but new screw holes must be drilled. Using the included adapter brackets they can be mounted in a variety of 6-1/2" and 6-3/4" applications, without any modification. Enter you vehicle information to confirm fit.
| General | ||
|---|---|---|
| Speaker Size | 6 3/4 | |
| Design | 2-way | |
| Tweeter Design | 1" Dome | |
| Tweeter Composition | Cloth | |
| Woofer Composition | Injection-Molded Polypropylene | |
| Woofer Surround | Rubber | |
| Parts Warranty | 2 Years | |
| Labor Warranty | 2 Years | |
| Specifications | ||
| Sensitivity (1W at 1 meter) | 88 | |
| Sensitivity at 2.83 volts | N/A | |
| Frequency Response | 69 - 21k Hz | |
| Minimum RMS Wattage | --- | |
| Maximum RMS Wattage | 80 | |
| Peak Power Handling (Watts) | 240 | |
| Impedance (Ohms) | 4 | |
| Top-mount Depth (Inches) | 2 1/4 | |
| Bottom-mount Depth (Inches) | N/A | |
| Cutout Diameter or Length (inches) | 5 | |
