AudioControl ACM 4.300 4-Channel Micro Power Amplifier - High Performance Car Audio System for Enhanced Sound Quality | Perfect for Car Stereo Upgrades & Custom Installations[90095216]
-45%
$274.97
List Price:
$499.95
Delivery & Return: Free shipping on all orders over $50
Delivery Time: 10-15 days international
24 peoples viewing this product right now!
Guranteed safe checkout
Product Description
Summary
- 4 x 75 watts @ 2 ohms
- 4 x 50 watts @ 4 ohms
- 150 watts @ 4 ohms bridged
- GTOTM Signal Sense
- Active speaker-level inputs for OEM integration
- RCA Line Inputs
- Linkwitz-Riley Crossover
- Reversible Cover Plate
- Bulletproof 5 year warranty (when installed by an authorized AudioControl dealer)
Overview
ACM series amplifiers by AudioControl are the perfect blend of power and features for car audio systems from mild to wild. Compact size, high power and the ability to help integrate with factory stereo systems are features that assure “Making Good Sound Great” can happen in any installation.
Reversible cover plates allow flexible mounting options when paired with AudioControl DM Series Processors or when using multiple ACM series amplifiers in confined spaces. Once again AudioControl comes to the rescue combining features and benefits needed to assure audio euphoria in an automotive setting.
SPECIFICATIONS:
Inputs:
Preamp Inputs: 4 Balanced
Preamp Input Voltage Range: 500 mV – 6 V RMS
Speaker Level Inputs: 4
Outputs:
Rated Continuous (RMS) Power at 14.4V:
4 Ω – 50 W x 4 RMS
2 Ω – 75 W x 4 RMS
Bridged 4 Ω – 150 W RMS
Performance:
Frequency Response: 10 Hz – 22 kHz
Signal to Noise: 102 dBA, Ref 50 W @ 4 Ohm
THD+N: < 0.01%
Power / Ground Wire Gauge: 10 to 4 AWG wire
Fuse Rating: 1 x 30 A
Crossover: 12 dB/octave Linkwitz-Riley, 80 Hz, 120 Hz, Bypass
PFM Subsonic Filter: 32 Hz
Weights & Dimensions:
Dimensions: 9.4″W x 3.0″D x 1.75″H
Weight: 1.3 lbs. (0.6kg)
In the box:
ACM-4.300, Speaker Connectors, Fuse, Manual, Warranty
